Magnavox VC-8040
Jump to navigation
Jump to search
| Release Info | |
|---|---|
| Manufacturer | Magnavox |
| Release Date | June 1984 |
| Country | US |
| Color Encoding System | NTSC |
| Features | |
| Playable Disc Formats | LD, LD 20cm |
| Playable LaserDisc Modes | CAV, CLV |
| Both-Side Play | None |
| CX Noise Reduction | Yes |
| Video Characteristics | |
| Horizontal Resolution (TVL) | |
| Video Signal-to-Noise Ratio | 42dB |
| Laser Type | Infrared Diode |
| Laser Wavelength | 780 |
| Digital Video Processor | None |
| Analog Audio Characteristics | |
| Frequency Response | 40-20,000Hz |
| Signal-to-Noise Ratio | 75dB |
| Digital Audio Characteristics | |
| Frequency Response | |
| Signal-to-Noise Ratio | |
| Power Characteristics | |
| Input Voltage | 120V |
| Power Frequency | 60Hz |
| Power Consumption | 33W |
| Physical Characteristics | |
| Dimensions (W x H x D) | 420 x 120 x 414.8mm |
| Weight | 12.4kg |
| Loading Belt Part No. | |
| Accessories | |
| Remote Control | |
| Photos | |
|---|---|
 | |
 | |
| AV Outputs | |
| Video | Outputs |
Composite  |
1 RCA |
S-Video  |
0 |
VHF  |
1 F-Type |
DC VHF  |
0 |
SCART  |
0 |
| Audio | |
Audio (Mono)  |
0 |
Audio (Stereo)  |
1 RCA |
AC-3 RF  |
0 |
Coaxial Digital  |
0 |
Optical Digital  |
0 |
| Remote Control | |
| Remote Input |
0 |
| Remote Output |
0 |
Manuals
Technical Data References
Other Information
Referred to on other lists as the VC-8040GY or VC‑800GYOi, because the full model number is technically "VC-8040 GY01". However, most of Magnavox's models seem to append a GY01 to the label on the rear of the player. Full reference to this player found in The Educators' Handbook to Interactive Videodisc
