Pioneer CLD-1010
Jump to navigation
Jump to search
| Release Info | |
|---|---|
| Manufacturer | Pioneer |
| Release Date | May 1987 [1] |
| Country | US |
| Color Encoding System | NTSC |
| Features | |
| Playable Disc Formats | LD, CD, CDV |
| Playable LaserDisc Modes | CAV, CLV |
| Both-Side Play | None |
| CX Noise Reduction | Yes |
| Video Characteristics | |
| Horizontal Resolution (TVL) | 420 lines |
| Video Signal-to-Noise Ratio | |
| Laser Type | Infrared Diode |
| Laser Wavelength | 780 |
| Digital Video Processor | None |
| Analog Audio Characteristics | |
| Frequency Response | |
| Signal-to-Noise Ratio | |
| Digital Audio Characteristics | |
| Frequency Response | 4-20,000Hz |
| Signal-to-Noise Ratio | 98dB |
| Power Characteristics | |
| Input Voltage | 120V |
| Power Frequency | 50, 60Hz |
| Power Consumption | 48W |
| Physical Characteristics | |
| Dimensions (W x H x D) | 420 x 411 x 120mm |
| Weight | 11.5kg |
| Loading Belt Part No. | Pioneer VEB-125 |
| Accessories | |
| Remote Control | Pioneer CU-CLD004 |
| Photos | |
|---|---|
 | |
 | |
| AV Outputs | |
| Video | Outputs |
Composite  |
1 RCA |
S-Video  |
0 |
VHF  |
1 F-Type |
DC VHF  |
0 |
SCART  |
0 |
| Audio | |
Audio (Mono)  |
0 |
Audio (Stereo)  |
2 RCA (1 DAC) |
AC-3 RF  |
0 |
Coaxial Digital  |
0 |
Optical Digital  |
0 |
| Remote Control | |
| Remote Input |
1 Mini TRS |
| Remote Output |
1 Mini TRS |
Clone Model Numbers/Rebadges
Pioneer CLD-1050 • Pioneer CLD-70 • Denon DCD-GX
Manuals
Technical Data References
- ↑ https://global.pioneer/en/info/history/chronology/1980/ History of Pioneer Corporation 1980-1989
Other Information
2X Over Sampling Digital Filter. It also incorporates the same, superior analog video noise reduction circuitry that is contained in the Pioneer LD-W1 and the Pioneer LD-S1.[1]
Model Types: CLD-1010/KUC (US/Canada), CLD-1010/S/G (U.S. Military).
CLD-1010/S/G model type has selectable voltage of AC 110/120/220/240V, 50/60Hz, 44W
